Gefen převodník VGA na DVI a Scaler EXT-VGA-DVI-SC

Gefen převodník VGA na DVI a Scaler EXT-VGA-DVI-SC   -



Scale and convert video from a VGA source for use with a DVI Display

Features:

Converts and scales VGA to DVI
Input resolutions up to 1920 x 1200 (WUXGA)
Output resolutions up to 1080p60 and 1920 x 1200 (WUXGA)
On-screen display (OSD) menu allows easy set-up and control
Aspect Ratio Control: Full Screen, Panoramic, Letter/Pillar, Extract/Crop
Test Pattern Generator for quick system configuration
Gefen Syner-G™ simplifies in-field firmware updates and advanced EDID management including custom input timings
USB port for use with Gefen Syner-G™
Wide power supply operating range (6V to 24V DC)
Locking power supply connector
Surface mountab

Tec. Spec.:



   Maximum Pixel Clock: 165 MHz
   Maximum TMDS Clock: 165 MHz
   Video Input Connector: (1) VGA HD-15, female
   Video Output Connectors: (1) DVI-I, 29-pin, female
   (digital only)
   USB Connector: (1) Mini-B
   Menu/Navigation Switches: (3) tact-type
   Power Indicator: (1) LED, blue
   Power Supply Connector: (1) 3-pin, locking
   Power Supply: 12V DC nominal (6V to 24V DC operating range)
  Dimensions (excluding connectors, W x H x D): 4.9" x 1" x 3.2" (123mm x 26mm x 82mm)
    Unit Weight: 0.4 lbs. (0.2kg)




Package includes:
   (1) VGA to DVI Scaler / Converter (EXT-VGA-DVI-SC)
   (1) 6 ft. VGA Cable (CAB-VGA-6MM-O)
   (1) 12V DC Power Supply (EXT-PS121.5AIP-3P)
   (1) Quick-Start Guide (QSG-EXT-VGA-DVI-SC)
