MacPower TAURUS RAID II R4 LCD Pleiades SATA box (2x 3.5 HDD) - FW 800 FW 400 USB 2.0 eSATA RAID 0, 1 , JBOD

Produkt End of life, nahrazeno MP-TAU-SUPER-S3-LCM

Hliníkový case pro 2 SATA disky MacPower TAURUS - 2x FireWire 800 + 1 x FireWire 400 a USB 2.0 a eSATA s funkcí RAID - ochrana dat pomocí zrcadlení disků ( mirror ) nebo rychlé pole ( strip ) . Evoluce původního modelu -  jiný RAID selektor , vstup na Kensington lock , JBOD mod , řízený ventilátor a antivibrační  systém .

Možnost nastavit vlastní úroveň RAIDU:

• RAID 0 Stripping
• RAID 1 Mirroring

• Spanning ( JBOD )

Hliníkový case s perforací a aktivním pomaloběžným ventilátorem - výborné chlazení a tichý chod . Chipset Oxford Agere 924 DSB .

Model No.  PDD-SAFBA5U2OS

Maximální velikost disků :  závislá na firmware , k 07/2009   2x 1.5TB ,

nové firmwary dostupné na www.macpower.com.tw

Bridge Chipset :Oxford 924 DSBs podporou > 2TB

Colour : Silver

Case Material : High quality aluminium for optimised heat dissipation

Application : Two 3.5" SATA-I or SATA-II Hard Drives (1.5Gb/s) For RAID 0 & 1, two hard hard drives of identical capacity and make are required

Features : Configurable RAID function for 2 drives (RAID 1 mirroring, RAID 0 using striping or spanning or Non-RAID)

Conectivity :

• USB 2.0
• FireWire 400
• FireWire 800
• eSATA


Data Transfer :

• eSATA up to 300MB /s

• Firewire 800 (1394b) up to 800Mbps (100MB/s)
• FireWire 400 (1394a) up to 400Mbps (50MB/s)
• USB 2.0 up to 480Mbps (60MB/s)
• USB 1.1 up to 12Mbps (1.5MB/s)

System Requirements (PC):

• FireWire 800 (1394b): Windows 2000/XP or above
• FireWire 400 (1394a): Windows 2000/XP or above
• USB 2.0: Windows 2000/XP or above
• USB 1.1: Windows 2000/XP or above
• eSATA port  XP , Vista , Win 7

• Your hardware device must have the correct corresponding port (eg. USB 2.0, USB 1.1 or PCI card).



System Requirements (Mac) :

• eSATA Mac OSX 10.4and higher

• FireWire 800 (1394b): Mac OS 10.2 or higher
• FireWire 400 (1394a): Mac OS 9.2 or higher
• USB 2.0: Mac OS 10.2 or higher
• USB 1.1: Mac OS 9.2 or higher
• Your hardware device must have the correct corresponding port (eg. USB 2.0, USB 1.1 or PCI card).

Power Supply :

External Power Adapter universal auto-switching (UL, cUL, CE, TUV approved) Input: AC 100-240V , Output: DC +12V/3A, +5V/4.2A

Enclosure Size  :24.5cm x 14.0cm x 8.3cm

Packing Accessories :

• Pleiades Taurus Enclosure
• USB 2.0 cable

• eSATA cable

• Firewire 1394a cable (6 to 6pin)
• Firewire 1394b cable (9 to 9pin)
• Power adapter plus cord, feet, screw package, manual

* For RAID 0 & 1, two hard hard drives of identical capacity and make are required!
